Disconnector

Details

Uses:

It is used for working conditions with small tubing diameter and large diameter of pumping pump, or used in special oil pump.

Structure:

The disconnector consists of an upper assembly consisting of a righting joint and a claw spring, a core rod, a locking sleeve, a spring and a lower joint.

The lower assembly and the release joint are composed of three parts.

Features:

1. The structure is reasonable, the radial size is compact, and it can enter the pump barrel without increasing the operation process;

2. It has a self-locking structure, high success rate of connection and disconnection, and reliable operation;

3. It adopts high-quality spring steel and alloy structural steel, which has small butt joint and disengagement force and large bearing capacity;

4. It is treated with chemical plating and anti-corrosion treatment to extend the service life.
